CNCF-sponsored service Mesh Linkerd provides a lot of needed features in nowadays microservices architectures.
If you are reading this, probably, you are already aware of the challenges that come with a microservices architecture. It could be because you are reading about those or even because you are challenging them right now in your own skin.
One of the most common challenges is network and communication. With the eclosion of many components that need communication and the ephemeral approach of the cloud-native developments, many new features are a need when in the past were just a nice-to-have.
Concepts like service registry and service discovery, service authentication, dynamic routing policies, and circuit breaker patterns are no longer things that all the cool companies are doing but something basic to master the new microservice architecture as part of a cloud-native architecture platform, and here is where the Service Mesh project is increasing its popularity as a solution for most of this challenges and providing these features that are needed.
If you remember, a long time ago, I already cover that topic to introduce Istio as one of the options that we have:
Integrating Istio with BWCE Applications
Introduction Services Mesh is one the “greatest new thing” in our PaaS environments. No matter if you’re working with K8S, Docker Swarm, pure-cloud with EKS or AWS, you’ve heard and probably tried to know how can be used this new thing that has so many advantages because it provides a lot of options in handling […]
But this project created by Google and IBM is not the only option that you have to provide those capabilities. As part of the Cloud Native Computing Foundation (CNCF), the Linkerd project provides similar features.
How to install Linkerd
To start using Linkerd, the first thing that we need to do is to install the software and to do that. We need to do two installations, one on the Kubernetes server and another on the host.
To install on the host, you need to go to the releases page and download the edition for your OS and install it.
I am using a Windows-based system in my sample, so I use chocolatey to install the client. After doing so, I can see the version of the CLI typing the following command:
linkerd version
And you will get an output that will say something similar to this:
PS C:\WINDOWS\system32> linkerd.exe version
Client version: stable-2.8.1
Server version: unavailable
Now we need to do the installation on the Kubernetes server, and to do so, we use the following command:
linkerd install | kubectl apply -f -
And you will get an output similar to this one:
PS C:\WINDOWS\system32> linkerd install | kubectl apply -f -
namespace/linkerd created
clusterrole.rbac.authorization.k8s.io/linkerd-linkerd-identity created
clusterrolebinding.rbac.authorization.k8s.io/linkerd-linkerd-identity created
serviceaccount/linkerd-identity created
clusterrole.rbac.authorization.k8s.io/linkerd-linkerd-controller created
clusterrolebinding.rbac.authorization.k8s.io/linkerd-linkerd-controller created
serviceaccount/linkerd-controller created
clusterrole.rbac.authorization.k8s.io/linkerd-linkerd-destination created
clusterrolebinding.rbac.authorization.k8s.io/linkerd-linkerd-destination created
serviceaccount/linkerd-destination created
role.rbac.authorization.k8s.io/linkerd-heartbeat created
rolebinding.rbac.authorization.k8s.io/linkerd-heartbeat created
serviceaccount/linkerd-heartbeat created
role.rbac.authorization.k8s.io/linkerd-web created
rolebinding.rbac.authorization.k8s.io/linkerd-web created
clusterrole.rbac.authorization.k8s.io/linkerd-linkerd-web-check created
clusterrolebinding.rbac.authorization.k8s.io/linkerd-linkerd-web-check created
clusterrolebinding.rbac.authorization.k8s.io/linkerd-linkerd-web-admin created
serviceaccount/linkerd-web created
customresourcedefinition.apiextensions.k8s.io/serviceprofiles.linkerd.io created
customresourcedefinition.apiextensions.k8s.io/trafficsplits.split.smi-spec.io created
clusterrole.rbac.authorization.k8s.io/linkerd-linkerd-prometheus created
clusterrolebinding.rbac.authorization.k8s.io/linkerd-linkerd-prometheus created
serviceaccount/linkerd-prometheus created
clusterrole.rbac.authorization.k8s.io/linkerd-linkerd-proxy-injector created
clusterrolebinding.rbac.authorization.k8s.io/linkerd-linkerd-proxy-injector created
serviceaccount/linkerd-proxy-injector created
secret/linkerd-proxy-injector-tls created
mutatingwebhookconfiguration.admissionregistration.k8s.io/linkerd-proxy-injector-webhook-config created
clusterrole.rbac.authorization.k8s.io/linkerd-linkerd-sp-validator created
clusterrolebinding.rbac.authorization.k8s.io/linkerd-linkerd-sp-validator created
serviceaccount/linkerd-sp-validator created
secret/linkerd-sp-validator-tls created
validatingwebhookconfiguration.admissionregistration.k8s.io/linkerd-sp-validator-webhook-config created
clusterrole.rbac.authorization.k8s.io/linkerd-linkerd-tap created
clusterrole.rbac.authorization.k8s.io/linkerd-linkerd-tap-admin created
clusterrolebinding.rbac.authorization.k8s.io/linkerd-linkerd-tap created
clusterrolebinding.rbac.authorization.k8s.io/linkerd-linkerd-tap-auth-delegator created
serviceaccount/linkerd-tap created
rolebinding.rbac.authorization.k8s.io/linkerd-linkerd-tap-auth-reader created
secret/linkerd-tap-tls created
apiservice.apiregistration.k8s.io/v1alpha1.tap.linkerd.io created
podsecuritypolicy.policy/linkerd-linkerd-control-plane created
role.rbac.authorization.k8s.io/linkerd-psp created
rolebinding.rbac.authorization.k8s.io/linkerd-psp created
configmap/linkerd-config created
secret/linkerd-identity-issuer created
service/linkerd-identity created
deployment.apps/linkerd-identity created
service/linkerd-controller-api created
deployment.apps/linkerd-controller created
service/linkerd-dst created
deployment.apps/linkerd-destination created
cronjob.batch/linkerd-heartbeat created
service/linkerd-web created
deployment.apps/linkerd-web created
configmap/linkerd-prometheus-config created
service/linkerd-prometheus created
deployment.apps/linkerd-prometheus created
deployment.apps/linkerd-proxy-injector created
service/linkerd-proxy-injector created
service/linkerd-sp-validator created
deployment.apps/linkerd-sp-validator created
service/linkerd-tap created
deployment.apps/linkerd-tap created
configmap/linkerd-config-addons created
serviceaccount/linkerd-grafana created
configmap/linkerd-grafana-config created
service/linkerd-grafana created
deployment.apps/linkerd-grafana created
Now we can check that the installation has been done properly using the command:
linkerd check
And if everything has been done properly, you will get an output like this one:
PS C:\WINDOWS\system32> linkerd check
kubernetes-api
--------------
√ can initialize the client
√ can query the Kubernetes API
kubernetes-version
------------------
√ is running the minimum Kubernetes API version
√ is running the minimum kubectl version
linkerd-existence
-----------------
√ 'linkerd-config' config map exists
√ heartbeat ServiceAccount exist
√ control plane replica sets are ready
√ no unschedulable pods
√ controller pod is running
√ can initialize the client
√ can query the control plane API
linkerd-config
--------------
√ control plane Namespace exists
√ control plane ClusterRoles exist
√ control plane ClusterRoleBindings exist
√ control plane ServiceAccounts exist
√ control plane CustomResourceDefinitions exist
√ control plane MutatingWebhookConfigurations exist
√ control plane ValidatingWebhookConfigurations exist
√ control plane PodSecurityPolicies exist
linkerd-identity
----------------
√ certificate config is valid
√ trust anchors are using supported crypto algorithm
√ trust anchors are within their validity period
√ trust anchors are valid for at least 60 days
√ issuer cert is using supported crypto algorithm
√ issuer cert is within its validity period
√ issuer cert is valid for at least 60 days
√ issuer cert is issued by the trust anchor
Then we can see the dashboard from Linkerd using the following command:
linkerd dashboard
Dashboard initial web page after a clean Linkerd installation
Deployment of the apps
We will use the same apps that we use some time ago to deploy istio, so if you want to remember what they are doing, you need to look again at that article.
And if we reach the endpoint, we got the expected reply from the provider.
Sample response provided by the provider
And in the dashboard, we can see the stats of the provider:
Linkerd dashboard showing the stats of the flow
Also, linked by default provided a Grafana dashboard where you can see more metrics you can get there using the grafana link that the dashboard has.
Grafana link on the Linkerd Dashboard
When you enter that, you could see something like the dashboard shown below:
Grafana dashboard showing the linkerd statistics
Summary
With all this process, we have seen how easily we can deploy a linkerd service mesh in our Kubernetes cluster and how applications can integrate and interact with them. In the next posts, we will dive into the most advanced features that will help us in the new challenges that come with the Microservices architecture.
